Máy quét mã vạch Datalogic Gryphon I GM4100 1D / GM4130

Liên hệ: +84 907 669 388

Tình trạng: Có sẳn


Máy quét mã vạch ảnh tuyến tính không dây Gryphon GM4100 1D vô cùng bền, đa năng là giải pháp tốt nhất cho các ứng dụng trong môi trường bán lẻ và ánh sáng nhẹ, nơi mà sự di động là cần thiết để nâng cao năng suất.

MOBILE SCANNER WITH NARROW BAND RADIO

The Datalogic Gryphon GM4100 cordless linear imaging readers offer the richest feature set among general purpose product offerings. Featuring narrow band radio communications with Datalogic’s STAR Cordless System, the Gryphon GM4100 reader provides increased productivity and flexibility in the workplace.

The GM4100 reader series offers scalable solutions from simple point-to-point applications to point-to-multipoint installations with up to 16 readers connected to the same base station. The GM4100 readers ‘Batch Mode’ capability allows thousands of codes to be stored in its’ memory. This feature, combined with a long-lasting 60,000 scans-per-charge Lithium-Ion battery allows uninterrupted scanning with unlimited mobility

An optional display with a 3-button keypad provides battery status, radio coverage indicator and enables operator interaction with the host system. Mobile communications also eliminate the restraints caused by cabled devices, providing a safer and more efficient environment for employees.


BATCH MODE

GM4100 Batch Mode capability allows thousands of codes to be stored in memory. This feature combined with a long lasting 50K scans per charge Lithium-Ion battery allows unlimited mobility and reliable data collection when out-of-range from the base station.


DATALOGIC PATENTED 'GREEN SPOT' TECHNOLOGY

Featuring Datalogic’s exclusive patented ‘Green Spot’ for good read feedback directly on the code, it helps to improve productivity especially in noisy environments. When using the product with the cradle at a 45° position, the Green Spot can work as an aiming system remaining on to aid in positioning the code for quick and intuitive reading.

MULTI-INTERFACE CAPABILITY

Standard multi-interface capabilities (GM4130) provide host connectivity via USB, RS-232, Keyboard Wedge and Wand Emulation while IBM interface models (GM4110) provide connectivity via IBM 46XX, USB and RS-232 emulation. The Datalogic Aladdin™ configuration program provides user-friendly features that simplify the start-up procedure, even for inexperienced users.

SUITABLE APPLICATIONS

  • Manufacturing
  • Entertainment
  • Healthcare
  • Convenience Store
  • Warehousing

DECODING CAPABILITY


 1D / Linear Codes:
Auto discriminates all standard 1D codes includingGS1 DataBar™ linear codes   Stacked Codes:

EAN/JAN Composites; GS1 DataBar Composites;GS1 DataBar Expanded Stacked;
GS1 DataBarStacked; GS1 DataBar Stacked Omnidirectional


READING PERFORMANCE


Light Source:
Illumination: Red LED ARRAY 630 - 670 nm

 Imager Sensor:
CCD Solid-state 2048 pixels


Print Contrast Ratio (Minimum):
15%

Read Rate (Maximum):
325 reads/sec.

Reading Angle:
Pitch: 65°; Roll (Tilt): 35°; Skew (Yaw): 65°

Reading Indicators:
Beeper (Adjustable Tone and Volume); Datalogic ‘Green Spot’
Good Read Feedback; Good Read LED.

Resolution (Maximum):
0.076 mm / 3 mils (1D Codes)



ENVIRONMENTAL


Drop Resistance:
Withstands repeated drops from 1.8 m/5.9 ft onto a concrete surface

Particulate and Water Sealing:
IP52

Temperature Operating:
0 to 50 °C / 32 to 122 °F

Storage/Transport:
-20 to 70 °C / -4 to 158 °F


Máy quét mã vạch ảnh tuyến tính không dây Gryphon GM4100 1D vô cùng bền, đa năng là giải pháp tốt nhất cho các ứng dụng trong môi trường bán lẻ và ánh sáng nhẹ, nơi mà sự di động là cần thiết để nâng cao năng suất.
